TEKA MAESTRO IZS 34700 MST modular induction Flex hob – 30 cm

Singular Features

• Modualar induction hob
• Touch control MultiSlider
• Flex Function
• SlideCooking Function
• 2 cooking zones:
• 1 induction Ø 255 x 200 mm
• 1 induction Ø 255 x 200 mm
• Direct Funtions: Simmering, Melting, Keep Warm, Grilling, Pan Frying, Deep Frying, Confit, Poach
• Residual heat indicators
• Fast-Click easy installation
• Power Plus function
• Stop & Go funtion
• Timmer
• Acoustic alarm
• Auto lock safety system
• Child lock safety system
• Maximum nominal power : 3.600 W

Technical Details

General measures

• Product height (mm): 53
• Product width (mm): 300
• Product depth (mm): 510
• Net weight (Kg): 5,12

 View technical drawing

Fitting measures

• Built-in Width (mm): 280
• Built-in Depth (mm): 490
• Built-in height (mm): 49

Particular characterisitics

• Number of electric power levels: 9
• Grilling: Yes
• Pan frying: Yes
• Deep frying: Yes
• Simmering: Yes
• Keeping warm: Yes
• Confit: Yes
• Poach: Yes
• Power management function: Yes

Electric connection

• Frequency (Hz): 50/60
• Power rate (V): 220-240
• Cable Connection Length (cm): 110
• Maximum Nominal Power (W) (Electric hob): 3600

Cooking zones

• Cooking Zones: 2

Security system

• Residual heat indicator (Electric hob): Yes
• Automatic safety disconnection (Auto Lock) (Electric hob): Yes

Finish

• Surface finishing: Front bevelled glass
• Surface type: Ceramic Glass (4mm)
• Easy installation system: Yes

Accessories

• Junction Kit: Optional
• Teppan Yaki: Optional
