TEKA MAESTRO DHT 97670 Built-In ceiling hood in 214mm height with FreshAir function and Rim extraction

Singular Features

• Ceiling hood
• Electronic control
• FreshAir function
• Rim extraction
• Remote control
• Brushless EcoPower Motor
• 4 speeds + 2 intensive
• Free Outlet exhaust capacity (m3/h): 800
• Max speed exhaust capacity (m3/h): 808
• Min speed exhaust capacity (m3/h): 315
• Intensive speed exhaust capacity (m3/h): 686
• Intensive speed sound level (dBA): 70
• Max speed sound level (dBA): 67
• Min speed sound level (dBA): 50
• 3 LED lamps
• Light intensity regulation
• 2 Aluminum filter
• Stop delay timer
• Filter saturation indicator
• Operating pilot light
• Outlet reduction optional
• Optional Charcoal Filter: R1RES

Technical Details

General measures

• Product height (mm): 214
• Product width (mm): 900
• Product depth (mm): 600
• Net weight (Kg): 25

 View technical drawing

Particular characterisitics

• Ø Outlet (mm): 215×85
• Type of inner light: LED
• Inside light Consumption (W): 2,2
• Plug type: Schuko
• Cable Connection Length (cm): 150
• Power rate (V): 220-240
• Frequency (Hz): 50-60
• Total hood power (W): 226,6
• Number of motors: 1
• Motor power (W): 220

Accessories

• Outlet reduction: Yes
• Regenerative charcoal filter: Yes

Models

• Number of filters: 2
• Filter description: Aluminum
• Opening system: Piston
• Control panel: Electronic with remote control
• Remote control: Yes
• Stop delay timer: Yes
• Filter saturation indicator: Yes
• Number of speeds: 4+2
• Fresh air function: Yes

Downloads

 Manuals

 Full product card

 Technical drawing

 High resolution images

 Energy label

EU Product Information Sheet
